IB-FXE is an integrated Code Sail Furler for multihulls, easy to use, easy to install.
IB-FXE CODE SAIL ELECTRIC FURLER BENEFITS
For Code Sails up to 180 M² :
⊕ Two models 4500 & 7000 (12 & 14V) perfectly adapted to other 38’ catamarans
⊕ Complete customizable kit : options complete a standard kit according to boat configuration
⊕ Easy to install, easy to use (wireless controller): for Gennakers, asymmetrical Spinnakers, Code sails,…
⊕ Effortless sailing concept : no furling line needed : easy sail handling, smooth design, waterproof!
⊕ Specifically adapted to catamarans (furler ready to use)
⊕ Available kits : Lagoon 42’(IB-FXE4500)
Lagoon 46’/51’ /52’/55’ (IB-FXE7000). > Contact us
IB-FXE : COMPLETE CUSTOMIZABLE KIT
– Integrated motorization in a specially designed bowsprit (whisker pole) & supplied at length
– Textile shackle (delivered) = easy connection for sail attachment
– Specific relay box + waterproof circuit breaker (delivered)
– Swivel and shackle
– Wireless (option) or wired controller (option)
– Special attachment & Wire bridles kit (option) or Textile bridles kit (option)
– Topping lift attachment (delivered).
– Back ends for bowsprit / crossbeam connection : 4 various configurations. > contact us.
IB-FXE TECHNICAL INFORMATIONS
| Model | Boat length (feet / m) | Ref. N° | max. Gennaker area (m2) | Power (W) | Furling speed (rpm) | Amps / Voltage (A/V) | Circuit breaker(A) | Dimensions (mm) | |
|---|---|---|---|---|---|---|---|---|---|
| IB-FXE 4500 12V | 38 < 43' 11,5 < 13m | Contact us | 90 m2 | 400 W max. | 85 rpm | 40 A Max (12V) | 40 A | ø 100 mm | On request |
| IB-FXE 4500 24V | 30 A Max (24V) | 30 A | |||||||
| IB-FXE 7000 12V | 43 < 55' 13 < 17m | Contact us | 180 m2 | 800 W max. | 110 rpm | 60 A Max (12V) | 60 A | ø 115 mm | On request |
| IB-FXE 7000 24V | 30 A Max (24V) | 30 A | |||||||
The installation of an electric motorized Code sails furler requires professional knowledge and authorization.
